SKU: N3UXOPQQ5ZEI

Acceleration sensor 0-10g for motor water pump Integrated piezoelectric vibration sensor transmitter 4-20mA

Categories: , ,
Attributes
Hign-concerned ChemicalNone
is_customizedYes
Model NumberDSH-V100
Brand NameData Shark
OriginMainland China
CertificationCE
Supply voltage18-30VDC
Measuring range0-400mm/s, 0-2000um, 0-20g
Output currenttwo-wire system 4-20mA (maximum load 500Ω)
View all attributes
View all attributes
Vendor
Mota
100% Consent
Security & Privacy
Crypto payment

Instock

Seller
$ 80.75

Fast & Free shipping

Fast & Free returns

24/7 support

Safe payments

Security & Privacy

Related products

BENETECH Vibration Analyzer Digital Vibration Meter Device Probe Analizador De Vibraciones Digital Handheld Vibrator Tester 1

BENETECH Vibration Analyzer Digital Vibration Meter Device Probe Analizador De Vibraciones Digital Handheld Vibrator Tester

Instock
$ 86.71
Close
BENETECH Vibration Analyzer Digital Vibration Meter Device Probe Analizador De Vibraciones Digital Handheld Vibrator Tester 2
UNI-T UT310 Series Handheld Digital Vibrometer UT311 UT315A / Measure Acceleration, Velocity, Displacement 1

UNI-T UT310 Series Handheld Digital Vibrometer UT311 UT315A / Measure Acceleration, Velocity, Displacement

Instock
$ 278.99
Close
UNI-T UT310 Series Handheld Digital Vibrometer UT311 UT315A / Measure Acceleration, Velocity, Displacement 2
HTI HT-1201 Portable LCD Vibration Analyzer Tester Meter Vibrometer Gauge 0.1-199.9m/s Digital Split Type Vibrometer 1

HTI HT-1201 Portable LCD Vibration Analyzer Tester Meter Vibrometer Gauge 0.1-199.9m/s Digital Split Type Vibrometer

Instock
$ 84.89
Close
HTI HT-1201 Portable LCD Vibration Analyzer Tester Meter Vibrometer Gauge 0.1-199.9m/s Digital Split Type Vibrometer 2
Digital Vibration Meter 0.1~199.9m/s High Precision Probe Type Detached Handheld Vibration Detector Tester Gauge Analyzer AS63B 1

Digital Vibration Meter 0.1~199.9m/s High Precision Probe Type Detached Handheld Vibration Detector Tester Gauge Analyzer AS63B

Instock
$ 97.74
Close
Digital Vibration Meter 0.1~199.9m/s High Precision Probe Type Detached Handheld Vibration Detector Tester Gauge Analyzer AS63B 2
3D Vibration Tester 3 Channels VM-6380-3 Digital Vibrometer 0.01-400mm/s True RMS 1

3D Vibration Tester 3 Channels VM-6380-3 Digital Vibrometer 0.01-400mm/s True RMS

Instock
$ 506.00
Close
3D Vibration Tester 3 Channels VM-6380-3 Digital Vibrometer 0.01-400mm/s True RMS 2
In Stock HT-1201 Portable Vibration Meter Analyzer 0.1~199.9m Ht-1201 Digital Split Type Vibrometer 1

In Stock HT-1201 Portable Vibration Meter Analyzer 0.1~199.9m Ht-1201 Digital Split Type Vibrometer

Instock
$ 70.91
Close
VM-6310 Portable Vibrometer Mechanical Motor Speed 0.01mm/s~ 200mm /s High-Precision Digital Vibration Measuring Instrument 1

VM-6310 Portable Vibrometer Mechanical Motor Speed 0.01mm/s~ 200mm /s High-Precision Digital Vibration Measuring Instrument

Instock
$ 195.13
Close
VM-6310 Portable Vibrometer Mechanical Motor Speed 0.01mm/s~ 200mm /s High-Precision Digital Vibration Measuring Instrument 2
Automobile spark plug detector test bench fire gauge diagnostic detector high pressure ignition system fire detection 1

Automobile spark plug detector test bench fire gauge diagnostic detector high pressure ignition system fire detection

Instock
$ 31.37
Close
Automobile spark plug detector test bench fire gauge diagnostic detector high pressure ignition system fire detection 2
Three axis vibration sensor single axis temperature RS485/LoRa transmitter high precision motor frequency monitoring 1

Three axis vibration sensor single axis temperature RS485/LoRa transmitter high precision motor frequency monitoring

Instock
$ 191.67
Close
Three axis vibration sensor single axis temperature RS485/LoRa transmitter high precision motor frequency monitoring 2
Vibration Meter VM-6360 10Hz~10KHz Vibration Analyzer Acceleration Displacement Motor Fault 0.01mm/s~400 mm/s 1

Vibration Meter VM-6360 10Hz~10KHz Vibration Analyzer Acceleration Displacement Motor Fault 0.01mm/s~400 mm/s

Instock
$ 214.48
Close
Vibration Meter VM-6360 10Hz~10KHz Vibration Analyzer Acceleration Displacement Motor Fault 0.01mm/s~400 mm/s 2

Additional information

Weight 0.5 kg
Dimensions 30 × 20 × 15 cm
Hign-concerned Chemical

None
is_customized

Yes
Model Number

DSH-V100
Brand Name

Data Shark
Origin

Mainland China
Certification

CE
Supply voltage

18-30VDC
Measuring range

0-400mm/s, 0-2000um, 0-20g
Output current

two-wire system 4-20mA (maximum load 500Ω)
Response frequency

10Hz-1000Hz
Accuracy

±1.5%F.S
Measurement direction

any direction
Output mode: two-wire system

two-wire system
Ambient temperature:

-20 to +85 degree
Shell material:

stainless steel
Protection class:

IP67/IP65
Mounting thread:

M6x1/M10x1/ other thread or magnetic mount
