| Weight | 1.5 kg |
|---|---|
| Dimensions | 16 × 10 × 5 cm |
| Hign-concerned Chemical | None |
| is_customized | Yes |
| Model Number | AV-160T |
| Brand Name | SOZZDA |
| Origin | Mainland China |
| Certification | CE |
| Transducer | Piezoelectric accelerometer |
| Accuracy | ±5%+2 digits |
| Measurement Range | Displacement 0.001-4.000 mm equivalent peak-peak / 0.04-160.0 mil, Velocity 0.1-400.0 mm/s true RMS / 0.004-16.00 inch/s, Acceleration 0.1-400.0 m/s² equivalent peak / 0.3-1312 ft/s² / 0.0-40g |
| Frequency Range | Displacement 10Hz. ~ 1kHz, Velocity 10Hz. ~1kHz, Acceleration 10Hz. ~ 10kHz, 1~20, 000Hz (Reading should be multiplied by 10 if the display shows 10) |
| Rotation Rate Range | 60~99, 990RPM(r/min) (Reading should be multiplied by 10 if the display shows 10) |
| Analogue Output | AC output 0~2.0V peak full scale (load resistance: above 10k) |
| Size | 140x70x30mm |
| Weight | 130g (Not including Batteries) |
Instock
Dynamic Balance Vibration Analyzer AV-160T Vibration Tachometer Non-contact Photoelectric Tachometer Measures RPM And Hz
